Pump and injector spares

Plunger rods, piston seals, check valves, rotor seals, needle seats and inlet filters, for Agilent, Shimadzu, Thermo and Waters pumps and autosamplers. The parts behind a drifting baseline, carryover, and a pressure trace that will not settle.

Parts listed here are aftermarket, not original manufacturer parts. Instrument names and part numbers are given so you can match a part to the one in your system, and they remain the trademarks of their owners. I do not print the manufacturer on the catalogue, because I source each order against your requirement rather than from one brand. The manufacturer, country of origin, rated life and warranty are all stated in the quote, before you decide anything. If you need an OEM part, say so and I will quote that instead. Parts are bought and resold by Chromkit, so one Canadian supplier invoices you in Canadian dollars and the customs entry is mine.

Pump and injector spares

Plunger rods, piston seals, check valves, rotor seals, needle seats and inlet filters, for Agilent, Shimadzu, Thermo and Waters pumps and autosamplers. The parts behind a drifting baseline, carryover, and a pressure trace that will not settle.

Request a quote →
Jump to

Agilent

23 parts
Illustration of a plunger rod and pump seal. Generic drawing, not a photograph of this part. Illustration

Sapphire plunger rod for Agilent 1220, 1260 and 1290

Sapphire plunger rod for the Agilent 1220, 1260 and 1290, cross-referenced to 5067-4695. These are the later pump heads, and on a 1290 running near its pressure ceiling the plunger and seal both wear faster than the same parts in an 1100 ever did, so the service interval that suited your old stack will not suit this one. Inspect the rod when the seal is changed. A scored band where the seal rides means both parts go together, whatever the hours say.

Type
Sapphire plunger rod
Fits
Agilent 1220, 1260, 1290
Replaces
5067-4695

Price on request

Enquire

Request a quote
Illustration of a plunger rod and pump seal. Generic drawing, not a photograph of this part. Illustration

Active inlet valve cartridge, 400 bar, for Agilent A-series pumps (G1310A, G1311A, G1312A)

Aftermarket active inlet valve cartridge, 400 bar, for the Agilent G1310A, G1311A, G1312A, and the 1260 Infinity capillary and nano pumps, see the full fitment list above, cross-referenced to 5062-8562. A valve that is not seating shows up as pressure that swings with the pump stroke. Clean it before replacing it, because a trapped particle gives the same symptom as a worn seat.

Type
Active inlet valve cartridge
Pressure rating
400 bar
Fits
Agilent G1310A, G1311A, G1312A, and the 1260 Infinity capillary and nano pumps. These are found in 1100 and 1200 systems, and in 1260 capillary and nano systems
Replaces
5062-8562

Price on request

Enquire

Request a quote
Illustration of a plunger rod and pump seal. Generic drawing, not a photograph of this part. Illustration

Active inlet valve cartridge, 600 bar, for Agilent B-series pumps (G1311B, G1312B, G7111, G7112)

Aftermarket active inlet valve cartridge, 600 bar, for the Agilent G1310B, G1311B, G1312B, G7111A, see the full fitment list above, cross-referenced to G1312-60020. A valve that is not seating shows up as pressure that swings with the pump stroke. Clean it before replacing it, because a trapped particle gives the same symptom as a worn seat.

Type
Active inlet valve cartridge
Pressure rating
600 bar
Fits
Agilent G1310B, G1311B, G1312B, G7111A, G7111B, G7112A, G7112B. These are found in 1200, 1260 Infinity and Infinity II systems
Replaces
G1312-60020

Price on request

Enquire

Request a quote
Illustration of an injection needle and needle seat. Generic drawing, not a photograph of this part. Illustration

Needle seat, PEEK, 0.17 mm ID, for Agilent 1100 and 1200

PEEK needle seat, 0.17 mm internal diameter, cross-referenced to G1329-87017. The bore is the thing to get right: 0.17 mm is the standard analytical seat, and the narrower 0.12 mm version exists for low dispersion work at small injection volumes. Fitting the wrong one costs you peak shape rather than function, so it fails quietly. PEEK is softer than a stainless seat, which makes it forgiving of slight needle misalignment and shorter lived under heavy use.

Type
Needle seat, PEEK, 0.17 mm ID
Fits
Agilent 1100, 1120, 1200, 1220, 1260, G1313A, G1329A/B
Replaces
G1329-87017

Price on request

Enquire

Request a quote
Illustration of an injection needle and needle seat. Generic drawing, not a photograph of this part. Illustration

Needle seat, 0.12 mm ID, for Agilent 1100 and 1200

Needle seat, 0.12 mm internal diameter, cross-referenced to G1329-87012. The narrow bore version, for low dispersion work where the extra volume of a 0.17 mm seat would broaden an early eluting peak. If you run conventional 4.6 mm columns at normal injection volumes you probably want the wider seat instead, since the narrow bore blocks more easily on particulates. Check what is fitted before ordering, because the two look alike and only the bore differs.

Type
Needle seat, 0.12 mm ID
Fits
Agilent 1100, 1200, G1313A, G1329A, G1329B
Replaces
G1329-87012

Price on request

Enquire

Request a quote
Illustration of an injection needle and needle seat. Generic drawing, not a photograph of this part. Illustration

Needle assembly for Agilent 1100 and 1200 autosamplers

Needle assembly for the Agilent 1100 and 1200 autosampler, cross-referenced to G1313-87201. The complete assembly rather than the needle alone, which is the easier repair if the needle has been bent and you are not certain the mount survived it. A bent needle damages the seat it lands in, so inspect the seat at the same time and plan on changing both if the instrument has run a long time. Carryover a stronger wash will not shift usually means the tip.

Type
Needle assembly
Fits
Agilent 1100, 1120, 1200, 1220, 1260, G1313A, G1329A/B
Replaces
G1313-87201

Price on request

Enquire

Request a quote
Illustration of an injection needle and needle seat. Generic drawing, not a photograph of this part. Illustration

Needle, 900 uL, for Agilent 1100 and 1200 autosamplers

Injection needle, 900 uL, cross-referenced to G1313-87202. The 900 uL designation refers to the metering device this belongs with, not the injection volume you use day to day, so match it to the injector rather than to your method. The needle tip seals against the seat on every injection, and a blunted tip both leaks and scores the seat below it, which turns a cheap part into two. Inspect the seat whenever the needle is changed.

Type
Injection needle, 900 uL
Fits
Agilent 1100, 1200
Replaces
G1313-87202

Price on request

Enquire

Request a quote
Illustration of a plunger rod and pump seal. Generic drawing, not a photograph of this part. Illustration

Metering piston, 900 uL, for Agilent 1100 and 1200

Metering piston for the injector, 900 uL, cross-referenced to 5062-8587. A scored piston leaks past its seal, which gives injection volumes that read low and drift through a sequence. Replace the metering seal at the same time. A scored piston is usually what destroyed the seal in the first place, and a new seal running against the old piston repeats the fault within a few hundred injections. Before ordering either, inject one standard several times and look at area precision rather than retention. Areas drifting with retention steady points at the metering device.

Type
Metering piston, 900 uL
Fits
Agilent 1100, 1200, 1260, G1313A, G1329A/B, G1367E
Replaces
5062-8587

Price on request

Enquire

Request a quote
Illustration of a plunger rod and pump seal. Generic drawing, not a photograph of this part. Illustration

Piston seal, 900 uL, for Agilent 1100 injectors

Metering piston seal, 900 uL, cross-referenced to 0905-1294. This is the injector seal, not the pump one, and it fails into volume rather than pressure: areas that read low and drift down through a sequence while retention stays exactly where it was. Precision goes before accuracy. Inspect the metering piston when you change this, because a scored piston is usually what destroyed the seal, and a new seal running against the old piston repeats the fault within a few hundred injections.

Type
Metering piston seal, 900 uL
Fits
Agilent 1100, G1313A, G1329A/B, G1367E
Replaces
0905-1294

Price on request

Enquire

Request a quote
Illustration of a plunger rod and pump seal. Generic drawing, not a photograph of this part. Illustration

Sapphire plunger for Agilent 1100 and 1200 pumps

Sapphire plunger for the Agilent 1100 and 1200 pump head, cross-referenced to 5063-6586. Sapphire does not wear evenly against a seal. It develops a scored band exactly where the seal rides, and that band is what destroys the next seal you fit. Take the plunger out when you change a seal and look along it under magnification with a light behind it. A ring you can catch a fingernail on means both parts go. Fitting a new seal to a scored plunger buys a few hundred injections, not a service interval.

Type
Sapphire plunger
Fits
Agilent 1050, 1100, 1120, 1200, 1220, 1260, G1310A/B, G1311A/B/C, G1312A/B/C, G1376A, G2226A
Replaces
5063-6586

Price on request

Enquire

Request a quote
Illustration of a plunger rod and pump seal. Generic drawing, not a photograph of this part. Illustration

Gold piston seals for Agilent 1100 and 1200 pumps, 2 per pack

Aftermarket gold piston seals for the Agilent 1050, 1100, 1120, 1200, see the full fitment list above, cross-referenced to 0905-1420. As the seal wears, mobile phase leaks past the piston on the compression stroke, so pressure ripple rises and the baseline moves with it. If the plunger behind it is scored, change both, or the new seal fails early.

Type
Piston seals, gold, 2/pk
Fits
Agilent 1050, 1100, 1120, 1200, 1220, 1260, G1310A/B, G1311A/B/C, G1312A/B/C, G1376A, G2226A, G4302A
Replaces
0905-1420

Price on request

Enquire

Request a quote
Illustration of a plunger rod and pump seal. Generic drawing, not a photograph of this part. Illustration

Black piston seals for Agilent 1100 and 1200 pumps, 2 per pack

Aftermarket black piston seals for the Agilent 1050, 1100, 1120, 1200, 1220, 1260, cross-referenced to 5063-6589. As the seal wears, mobile phase leaks past the piston on the compression stroke, so pressure ripple rises and the baseline moves with it. If the plunger behind it is scored, change both, or the new seal fails early.

Type
Piston seals, black, 2/pk
Fits
Agilent 1050, 1100, 1120, 1200, 1220, 1260
Replaces
5063-6589

Price on request

Enquire

Request a quote
Illustration of a plunger rod and pump seal. Generic drawing, not a photograph of this part. Illustration

Plunger seal for Agilent 1100 and 1200 metering devices

Plunger seal for the metering device, cross-referenced to 5022-2175. This is the injector seal rather than the pump one, so it fails differently: instead of pressure ripple you get injection volumes that read low and areas that drift downward across a sequence while retention stays put. Precision goes before accuracy does. If your standard is losing area with every repeat injection and the pump is behaving, this is where I would look. Inspect the metering piston at the same time, since a scored piston is usually what killed the seal.

Type
Plunger seal
Fits
Agilent 1100, 1200, G1367D, G1389A, G1377A
Replaces
5022-2175

Price on request

Enquire

Request a quote
Illustration of a plunger rod and pump seal. Generic drawing, not a photograph of this part. Illustration

Pump seal for Agilent 1100 and 1200

Aftermarket pump seal for the Agilent 1050, 1100, 1120, 1200, 1220, 1260, G7129A, cross-referenced to 0905-1503. As the seal wears, mobile phase leaks past the piston on the compression stroke, so pressure ripple rises and the baseline moves with it. If the plunger behind it is scored, change both, or the new seal fails early.

Type
Pump seal
Fits
Agilent 1050, 1100, 1120, 1200, 1220, 1260, G7129A
Replaces
0905-1503

Price on request

Enquire

Request a quote
Illustration of a plunger rod and pump seal. Generic drawing, not a photograph of this part. Illustration

Wash seal for Agilent 1100 and 1200 pumps

Wash seal for the Agilent 1100 and 1200 pump, cross-referenced to 0905-1175. It sits behind the main piston seal and its job is to keep the wash solvent where it belongs, so it fails quietly: no pressure fault, just solvent appearing under the pump head or salt creeping up the plunger. That salt is what shortens the life of the seal in front of it. If you are replacing piston seals more often than the interval suggests, change this one and check the wash flow before you blame the seals.

Type
Wash seal
Fits
Agilent 1050, 1100, 1120, 1200, 1220, 1260
Replaces
0905-1175

Price on request

Enquire

Request a quote
Illustration of a plunger rod and pump seal. Generic drawing, not a photograph of this part. Illustration

Seal wash kit for Agilent 1100 and 1200 pumps

Seal wash kit for the Agilent 1100 and 1200, cross-referenced to G1310-68731. Seal wash is the maintenance that gets switched off and forgotten, and it is the single cheapest thing that extends piston seal life on a pump running buffers. Without it, salt crystallises on the plunger between runs and grinds the seal from the back. If you run phosphate or any high salt mobile phase and you are not washing, fitting this will save you more in seals than it costs. Use the wash solvent the manual specifies, not water alone.

Type
Seal wash kit
Fits
Agilent 1050, 1100, 1200
Replaces
G1310-68731

Price on request

Enquire

Request a quote
Illustration of an injection valve rotor seal. Generic drawing, not a photograph of this part. Illustration

Rotor seal, Vespel, 2-groove, for Agilent 1100 and 1200

Two groove Vespel rotor seal for the Agilent 1100 and 1200 injection valve, cross-referenced to 0100-1853. Count the grooves on the seal you take out before ordering, because the two groove and the standard pattern are not interchangeable and the valve body will accept the wrong one physically. Vespel is a polyimide, so it tolerates most solvents and dislikes high pH: mobile phases above about pH 10 shorten its life noticeably. A scored seal shows up as carryover first and injection precision second.

Type
Rotor seal, Vespel, 2-groove
Fits
Agilent 1100, 1200
Replaces
0100-1853

Price on request

Enquire

Request a quote
Illustration of an injection valve rotor seal. Generic drawing, not a photograph of this part. Illustration

Rotor seal, Vespel, for Agilent 1100 and 1200 injection valves

Vespel rotor seal for the Agilent 1100 and 1200 manual injection valve, cross-referenced to 0101-0623 and to the Rheodyne 7125 family. The seal is the wear part in the valve and the stator is not, so unless the stator face is damaged this is the only piece that should need replacing. Grooves worn into the seal let mobile phase cross between ports under pressure, which is why the symptom is carryover and a sample loop that never quite fills. Check the pH history of the method before assuming the seal was simply old.

Type
Rotor seal, Vespel
Fits
Agilent 1100, 1200. For valve p/n 0101-0921
Replaces
0100-1855

Price on request

Enquire

Request a quote
Illustration of an injection valve rotor seal. Generic drawing, not a photograph of this part. Illustration

Rotor seal, 2 position 6 port, 600 bar, for Agilent 1200 and 1260

Rotor seal for the 600 bar two position six port valve on the Agilent 1200 and 1260, cross-referenced to 0101-1416. The pressure rating is the thing to get right here. A 600 bar valve seal and a 400 bar one look similar and are not the same part, and fitting the lower rating into a system that runs near its ceiling gives you a seal that leaks internally within weeks. Check the valve part number rather than the system badge, because both pressure classes appear across the 1200 and 1260 range.

Type
Rotor seal, 2 position/6 port, Vespel, 600 bar
Fits
Agilent 1200, 1260
Replaces
0101-1416

Price on request

Enquire

Request a quote
Illustration of an injection valve rotor seal. Generic drawing, not a photograph of this part. Illustration

Manual injection valve rotor seal for Agilent 1100, 1200 and Rheodyne 7125

Aftermarket manual injection valve rotor seal for the Agilent 1100, 1200, PerkinElmer 200 Series, Rheodyne 7125, see the full fitment list above, cross-referenced to Agilent 0101-0623. A worn seal leaks between ports in the injection valve, which shows up as carryover, as low injection volume, or as a pressure step at the moment of injection.

Type
Rotor seal, Vespel, manual injection valve
Fits
Agilent 1100, 1200. PerkinElmer 200 Series. Rheodyne 7125, 7126, 7725, 7725i, 9725
Replaces
Agilent 0101-0623, PerkinElmer 09904802, Rheodyne 7125-047

Price on request

Enquire

Request a quote
Illustration of an inlet filter and frit. Generic drawing, not a photograph of this part. Illustration

Purge valve with PTFE frit for Agilent 1100, 1200 and 1260 pumps

Aftermarket purge valve with PTFE frit for the Agilent 1100, 1120, 1200, 1260, G1310A/B, G1311A/B/C, G1312A/B/C, G1376A, G2226A, cross-referenced to G1312-60071. A blocked filter starves the pump and shows up as pressure ripple, or as a pump that draws air on one channel. It is cheap, and it is blamed on the column far more often than it should be.

Type
Purge valve, long, with PTFE frit
Fits
Agilent 1100, 1120, 1200, 1260, G1310A/B, G1311A/B/C, G1312A/B/C, G1376A, G2226A
Replaces
G1312-60071

Price on request

Enquire

Request a quote
Illustration of an inlet filter and frit. Generic drawing, not a photograph of this part. Illustration

Glass solvent filter for Agilent 1100 and 1200

Aftermarket glass solvent filter for the Agilent 1050, 1090, 1100, 1200, 1220, 1260, 1290, cross-referenced to 5041-2168. A blocked filter starves the pump and shows up as pressure ripple, or as a pump that draws air on one channel. It is cheap, and it is blamed on the column far more often than it should be.

Type
Glass solvent inlet filter
Fits
Agilent 1050, 1090, 1100, 1200, 1220, 1260, 1290
Replaces
5041-2168

Price on request

Enquire

Request a quote
Illustration of an inlet filter and frit. Generic drawing, not a photograph of this part. Illustration

Stainless solvent inlet filter for Agilent 1100 and 1200

Aftermarket stainless solvent inlet filter for the Agilent 1050, 1090, 1100, 1200, cross-referenced to 01018-60025. A blocked filter starves the pump and shows up as pressure ripple, or as a pump that draws air on one channel. It is cheap, and it is blamed on the column far more often than it should be.

Type
Solvent inlet filter, stainless steel
Fits
Agilent 1050, 1090, 1100, 1200
Replaces
01018-60025

Price on request

Enquire

Request a quote

Shimadzu

12 parts
Illustration of a plunger rod and pump seal. Generic drawing, not a photograph of this part. Illustration

Sapphire plunger with holder for Shimadzu LC-20AD and LC-2010

Sapphire plunger with holder for the Shimadzu LC-20AD and LC-2010, cross-referenced to 228-35281-95. This is the assembled version, plunger already mounted in its holder, which is the easier fit if you are not confident seating a bare plunger squarely. A plunger that sits even slightly off axis wears its seal on one side and you get a pump that ripples on one channel only. If you have replaced a seal recently and the ripple came back within weeks, alignment rather than the seal is the thing to suspect.

Type
Sapphire plunger with holder
Fits
Shimadzu LC-10ADvp, LC-20AD/AB, LC-20ADXR, LC-30ADSF, LC-2010
Replaces
Shimadzu 228-35281-95, Sciex 4425124

Price on request

Enquire

Request a quote
Illustration of a plunger rod and pump seal. Generic drawing, not a photograph of this part. Illustration

Sapphire plunger for Shimadzu LC-20AD and LC-2010 pumps

Sapphire plunger for the LC-20AD and LC-2010 pump, cross-referenced to 228-34498-91. The bare plunger, for when the holder is sound and only the plunger is scored. Check that before ordering: if the holder is worn or the plunger will not seat squarely in it, the assembled version is the part you want instead. Look along the plunger with a light behind it and find the band where the seal rides. A ring you can feel means the seal you were about to fit will not last.

Type
Sapphire plunger
Fits
Shimadzu LC-10ADvp, LC-20AD/AB, LC-20ADXR, LC-30ADSF, LC-2010
Replaces
228-35601-93, old 228-34498-91, 228-35601-92

Price on request

Enquire

Request a quote
Illustration of a plunger rod and pump seal. Generic drawing, not a photograph of this part. Illustration

Sapphire plunger for Shimadzu SIL autosamplers and LC-2010

Sapphire plunger for Shimadzu SIL autosamplers and the LC-2010, cross-referenced to 228-35010-91. This is the autosampler plunger rather than the pump one, and the two are different parts despite looking alike, so check where the fault actually is before ordering. An autosampler plunger wears into injection volume error and carryover, not into pressure ripple. If your pressure trace is clean and your areas are drifting, you are in the right place; if the ripple is on the pump, you want the pump plunger.

Type
Sapphire plunger
Fits
Shimadzu i-Series, LC-2010 A/C HT, LC-HT, SIL-10ADvp, SIL-20A/AC, SIL-20ACHT, SIL-20ACXR, SIL-30AC, SIL-30ACMP, SIL-HTa, SIL-HTc
Replaces
228-35010-91

Price on request

Enquire

Request a quote
Illustration of a plunger rod and pump seal. Generic drawing, not a photograph of this part. Illustration

Plunger holder for Shimadzu LC-20AD and LC-2010 pumps

Plunger holder for the LC-20AD and LC-2010 pump, cross-referenced to 228-35602-91. The holder is what keeps the plunger square to the seal, and it is the part nobody suspects. A worn or distorted holder lets the plunger run slightly off axis, which wears the seal unevenly and gives you a pump that keeps failing on one channel however many seals you fit. If you are on your third seal in a year on the same head, stop buying seals and look at this instead.

Type
Plunger holder
Fits
Shimadzu LC-10ADvp, LC-20AB, LC-20AD, LC-20ADXR, LC-30AD, LC-2010
Replaces
228-35602-91

Price on request

Enquire

Request a quote
Illustration of a plunger rod and pump seal. Generic drawing, not a photograph of this part. Illustration

Plunger seal for Shimadzu LC-10AD, LC-20AD and LC-2010

Aftermarket plunger seal for the Shimadzu LC-9A, LC-10AD, LC-10ADvp, LC-20AD/AB, see the full fitment list above, cross-referenced to Shimadzu 228-35146-00. As the seal wears, mobile phase leaks past the piston on the compression stroke, so pressure ripple rises and the baseline moves with it. If the plunger behind it is scored, change both, or the new seal fails early.

Type
Plunger seal
Fits
Shimadzu LC-9A, LC-10AD, LC-10ADvp, LC-20AD/AB, LC-600, LC-2010 A/C HT, LC-40D, LC-2030
Replaces
Shimadzu 228-35146-00, old 228-18745-00, Sciex 445353

Price on request

Enquire

Request a quote
Illustration of a plunger rod and pump seal. Generic drawing, not a photograph of this part. Illustration

Plunger seal for Shimadzu LC-20AT and SIL autosamplers

Aftermarket plunger seal for the Shimadzu LC-10ATvp, LC-20AT, LC-2010 A/C HT, LC-HT, see the full fitment list above, cross-referenced to Shimadzu 228-35145-00. As the seal wears, mobile phase leaks past the piston on the compression stroke, so pressure ripple rises and the baseline moves with it. If the plunger behind it is scored, change both, or the new seal fails early.

Type
Plunger seal
Fits
Shimadzu LC-10ATvp, LC-20AT, LC-2010 A/C HT, LC-HT, SIL-HTa, SIL-HTc, SIL-10ADvp, SIL-20A/AC, SIL-20ACHT, SIL-20ACXR, SIL-30AC, SIL-30ACMP, SIL-2010 A/C HT
Replaces
Shimadzu 228-35145-00, Sciex 4425339

Price on request

Enquire

Request a quote
Illustration of a plunger rod and pump seal. Generic drawing, not a photograph of this part. Illustration

PTFE diaphragms for Shimadzu LC-20AD and LC-2010, 2 per pack

PTFE diaphragms for the LC-20AD and LC-2010, two per pack, cross-referenced to 228-24311-01. These sit in the degasser rather than the pump head. A perished diaphragm stops the degasser holding vacuum, and the symptom is dissolved gas reaching the pump: erratic pressure, a baseline that will not settle, and check valves that appear to be failing when they are only passing bubbles. Worth ruling out before you order valve cartridges, since it is the cheaper part and the more common cause of that particular pattern.

Type
PTFE diaphragm, 2/pk
Fits
Shimadzu LC-10AD, LC-10ADvp, LC-20AD/AB, LC-20ADXR, LC-30ADSF, LC-2010, LC-2010 HT
Replaces
Shimadzu 228-32784-91, old 228-24311-01 and 228-31828-00, Sciex 4425151

Price on request

Enquire

Request a quote
Illustration of an injection needle and needle seat. Generic drawing, not a photograph of this part. Illustration

Needle seal, Vespel, for Shimadzu LC-2010 and SIL-10ADvp

Vespel needle seal for the LC-2010 and SIL-10ADvp, cross-referenced to 228-33355-04. Vespel is the harder of the two materials Shimadzu uses here and it lasts longer, but it is less forgiving of a needle that is not perfectly aligned, and it dislikes high pH mobile phases. If your method runs above about pH 9 the PEEK version is usually the better choice. A worn seal leaks at injection, and the symptom is low and slightly variable areas rather than an obvious failure.

Type
Needle seal, Vespel
Fits
Shimadzu LC-2010, SIL-10ADvp, SIL-10AXL
Replaces
228-33355-04

Price on request

Enquire

Request a quote
Illustration of an injection needle and needle seat. Generic drawing, not a photograph of this part. Illustration

Needle seal, PEEK, for Shimadzu LC-2010 AHT and ACHT

PEEK needle seal for the LC-2010 AHT and ACHT, cross-referenced to 228-41540-01. PEEK is the softer of the two options, which makes it more tolerant of slight needle misalignment and better suited to high pH methods where Vespel degrades. The trade is a shorter working life under heavy use. Choose on your mobile phase rather than on price: if you run alkaline buffers, this is the one, and if you run a lot of injections at moderate pH, the Vespel version will outlast it.

Type
Needle seal, PEEK
Fits
Shimadzu LC-2010 AHT, LC-2010 ACHT
Replaces
228-41540-01

Price on request

Enquire

Request a quote
Illustration of an injection needle and needle seat. Generic drawing, not a photograph of this part. Illustration

Injection needle for Shimadzu LC-2010

Injection needle for the LC-2010, uncoated, 10 Series, cross-referenced to 228-41024-91. Uncoated is worth noting, because a coated needle is the usual answer to sample carryover with sticky or basic compounds, and this is not that part. A blunted or bent tip damages the needle seal below it, so if the needle has done a lot of injections, plan to change both. Carryover that a stronger wash does not fix, on a needle that has been in for years, usually means the tip rather than the wash.

Type
Injection needle, uncoated, 10 Series
Fits
Shimadzu LC-2010
Replaces
228-41024-91

Price on request

Enquire

Request a quote
Illustration of an injection valve rotor seal. Generic drawing, not a photograph of this part. Illustration

Low pressure valve rotor, PEEK, for Shimadzu LC-2010 and SIL-20A

Aftermarket low pressure valve rotor, PEEK, for the Shimadzu LC-2010, LC-2010 HT, SIL-20 A/C, SIL-20ACHT, SIL-20ACXR, SIL-HT, cross-referenced to Shimadzu 228-36923-00. A worn seal leaks between ports in the injection valve, which shows up as carryover, as low injection volume, or as a pressure step at the moment of injection.

Type
Rotor, PEEK, low pressure gradient valve
Fits
Shimadzu LC-2010, LC-2010 HT, SIL-20 A/C, SIL-20ACHT, SIL-20ACXR, SIL-HT
Replaces
Shimadzu 228-36923-00, Sciex 4427782

Price on request

Enquire

Request a quote
Illustration of an inlet filter and frit. Generic drawing, not a photograph of this part. Illustration

Line filter assembly for Shimadzu LC-20AD and LC-2010

Aftermarket line filter assembly for the Shimadzu i-Series, LC-10ADvp, LC-10AT, LC-10ATvp, see the full fitment list above, cross-referenced to Shimadzu 228-35871-96. A blocked filter starves the pump and shows up as pressure ripple, or as a pump that draws air on one channel. It is cheap, and it is blamed on the column far more often than it should be.

Type
Line filter assembly
Fits
Shimadzu i-Series, LC-10ADvp, LC-10AT, LC-10ATvp, LC-20AD/AB, LC-20ADXR, LC-20AR, LC-20AT, LC-30ADSF, LC-2010
Replaces
Shimadzu 228-35871-96, Sciex 4425351

Price on request

Enquire

Request a quote

Thermo Scientific

11 parts
Illustration of a plunger rod and pump seal. Generic drawing, not a photograph of this part. Illustration

Check valve cartridge for Thermo UltiMate 3000 pumps

Aftermarket check valve cartridge for the Thermo UltiMate 3000 series, DGP-3600BM/RS/SD, HPG-3200RS/SD, HPG-3400RS/SD, see the full fitment list above, cross-referenced to 6041.2301. A valve that is not seating shows up as pressure that swings with the pump stroke. Clean it before replacing it, because a trapped particle gives the same symptom as a worn seat.

Type
Check valve cartridge
Fits
Thermo UltiMate 3000 series. DGP-3600BM/RS/SD, HPG-3200RS/SD, HPG-3400RS/SD, ISO-3100BM/SD, LPG-3400BM/RS/SD, NCS-3500RS, NCP-3200RS, VF-P20
Replaces
6041.2301

Price on request

Enquire

Request a quote
Illustration of a plunger rod and pump seal. Generic drawing, not a photograph of this part. Illustration

Main piston seals for Thermo UltiMate 3000 RS pumps, 2 per pack

Aftermarket main piston seals for the Thermo HPG-3200RS, HPG-3400RS, LPG-3400RS, DGP-3600RS, cross-referenced to 6266.0305. As the seal wears, mobile phase leaks past the piston on the compression stroke, so pressure ripple rises and the baseline moves with it. If the plunger behind it is scored, change both, or the new seal fails early.

Type
Piston seal, main, reversed phase, 2/pk
Fits
Thermo HPG-3200RS, HPG-3400RS, LPG-3400RS, DGP-3600RS
Replaces
6266.0305

Price on request

Enquire

Request a quote
Illustration of a plunger rod and pump seal. Generic drawing, not a photograph of this part. Illustration

Piston seals for Thermo UltiMate 3000 RS and SD pumps, 2 per pack

Aftermarket piston seals for the Thermo UltiMate 3000 RS and SD pumps, ISO-3100SD, HPG-3200RS/SD, HPG-3400RS/SD, see the full fitment list above, cross-referenced to 6040.0304. As the seal wears, mobile phase leaks past the piston on the compression stroke, so pressure ripple rises and the baseline moves with it. If the plunger behind it is scored, change both, or the new seal fails early.

Type
Piston seals, reversed phase, 2/pk
Fits
Thermo UltiMate 3000 RS and SD pumps. ISO-3100SD, HPG-3200RS/SD, HPG-3400RS/SD, LPG-3400RS/SD, DGP-3600RS/SD
Replaces
6040.0304

Price on request

Enquire

Request a quote
Illustration of a plunger rod and pump seal. Generic drawing, not a photograph of this part. Illustration

Seal wash piston seals for Thermo UltiMate 3000 pumps, 2 per pack

Seal wash piston seals for the UltiMate 3000 pump, two per pack, cross-referenced to 6040.0033. These are the rear seals in the wash system rather than the main high pressure seals, and they are the ones that get overlooked. When they go you see wash solvent where it should not be and, eventually, main seals that fail early because salt is reaching them from behind. Order in pairs and change both, because a dual piston head with one new seal and one old one gives you an uneven ripple that is harder to diagnose than the original fault.

Type
Piston seals, seal wash system, 2/pk
Fits
Thermo ISO-3100BM/SD, HPG-3200RS/SD, HPG-3400RS/SD, LPG-3400RS/SD/XRS, DGP-3600RS/SD, VC-P10, VC-P20, VC-P32, VC-P40
Replaces
6040.0033

Price on request

Enquire

Request a quote
Illustration of a plunger rod and pump seal. Generic drawing, not a photograph of this part. Illustration

Pump head seals for Thermo UltiMate 3000

Aftermarket pump head seals for the Thermo UltiMate 3000 series, cross-referenced to 6040.2208. As the seal wears, mobile phase leaks past the piston on the compression stroke, so pressure ripple rises and the baseline moves with it. If the plunger behind it is scored, change both, or the new seal fails early.

Type
Pump head seals, PTFE, 2 sizes
Fits
Thermo UltiMate 3000 series
Replaces
6040.2208

Price on request

Enquire

Request a quote
Illustration of an injection valve rotor seal. Generic drawing, not a photograph of this part. Illustration

Rotor seal kit for Thermo UltiMate 3000 and WPS-3000

Rotor seal kit for the UltiMate 3000 and WPS-3000, cross-referenced to 6840.0012. Carryover on this autosampler is usually blamed on the needle and the wash, and the rotor seal is the quieter cause: worn grooves let a little of the previous sample cross between ports, so the carryover is proportional to the last concentration injected rather than constant. If a blank after a high standard is dirty but a blank after a blank is clean, that pattern points here rather than at the wash solvent.

Type
Rotor seal kit
Fits
Thermo WPS-3000, UltiMate 3000 series
Replaces
6840.0012

Price on request

Enquire

Request a quote
Illustration of an injection needle and needle seat. Generic drawing, not a photograph of this part. Illustration

Needle seat service kit for Thermo WPS-3000 autosamplers

Needle seat service kit for the WPS-3000, cross-referenced to 6820.0038A. The needle seat takes the needle on every injection and the seat face is what seals against it, so a scored or coned seat leaks at the moment of injection. The volume you lose is small and repeatable, which is what makes it hard to spot: everything is precise and everything is low. Inspect the seat whenever you change the needle, and change them as a pair if the instrument has done a lot of injections, since a worn needle tip is what damages the seat.

Type
Needle seat service kit
Fits
Thermo WPS-3000SL, WPS-3000RS, WPS-3000TXRS
Replaces
6820.0038A

Price on request

Enquire

Request a quote
Illustration of an injection needle and needle seat. Generic drawing, not a photograph of this part. Illustration

Viper sample needle for Thermo WPS-3000 autosamplers

Viper sample needle for the WPS-3000, cross-referenced to 6820.2432. Viper fittings are finger tight by design and that is the part people get wrong: over tightening with a tool deforms the cone and produces exactly the dead volume the fitting exists to avoid. A bent or blunted needle tip damages the seat below it, so if you are fitting a new needle it is worth inspecting the seat at the same time. Peak shape that has gone slightly tailing on every compound, rather than one, is worth checking here.

Type
Sample needle, Viper
Fits
Thermo WPS-3000SL, WPS-3000RS, WPS-3000TXRS
Replaces
6820.2432

Price on request

Enquire

Request a quote
Illustration of a metering syringe. Generic drawing, not a photograph of this part. Illustration

Metering syringe, 100 uL, for Thermo WPS-3000 autosamplers

Metering syringe, 100 uL, for the WPS-3000, cross-referenced to 6822.0002. The syringe meters the injection, so its wear shows up as volume rather than pressure: areas that read low, or precision that falls off at small injection volumes while large ones still look acceptable. That is the tell, because a worn plunger loses a fixed volume and a fixed volume matters more when you are injecting 2 uL than 50. If your low volume methods have gone imprecise and your high volume ones have not, this is the part.

Type
Metering syringe, 100 uL
Fits
Thermo WPS-3000
Replaces
6822.0002

Price on request

Enquire

Request a quote
Illustration of an inlet filter and frit. Generic drawing, not a photograph of this part. Illustration

Titanium filter frits for Thermo UltiMate 3000 pumps, 10 per pack

Aftermarket titanium filter frits for the Thermo UltiMate 3000 RS and SD pumps, cross-referenced to 6268.0111. A blocked filter starves the pump and shows up as pressure ripple, or as a pump that draws air on one channel. It is cheap, and it is blamed on the column far more often than it should be.

Type
Filter frit, titanium, 10 um, biocompatible, 10/pk
Fits
Thermo UltiMate 3000 RS and SD pumps
Replaces
6268.0111

Price on request

Enquire

Request a quote
Illustration of an inlet filter and frit. Generic drawing, not a photograph of this part. Illustration

Stainless filter frits for Thermo UltiMate 3000 pumps, 10 per pack

Aftermarket stainless filter frits for the Thermo UltiMate 3000 series, cross-referenced to 6268.011. A blocked filter starves the pump and shows up as pressure ripple, or as a pump that draws air on one channel. It is cheap, and it is blamed on the column far more often than it should be.

Type
Frit, solvent filter, stainless steel, 10 um, 10/pk
Fits
Thermo UltiMate 3000 series
Replaces
6268.011

Price on request

Enquire

Request a quote

Waters

2 parts
Illustration of a plunger rod and pump seal. Generic drawing, not a photograph of this part. Illustration

PerformancePLUS check valve cartridge for Waters 2695

Check valve cartridge for the Waters 2695 Alliance, cross-referenced to 700000254. A check valve that is not seating gives you a pressure trace that swings with the pump stroke, and the free test is worth running first: sonicate the cartridge in isopropanol and refit it. A valve held open by a particle or by precipitated buffer often recovers, and one that is genuinely worn does not. That five minute check separates the two and costs nothing.

Type
Check valve cartridge
Fits
Waters 2695 Alliance
Replaces
700000254

Price on request

Enquire

Request a quote
Illustration of a plunger rod and pump seal. Generic drawing, not a photograph of this part. Illustration

PerformancePLUS plunger assembly for Waters 2695 Alliance

Plunger assembly for the Waters 2695 Alliance, cross-referenced to WAT270959. The assembled part rather than a bare plunger, which is the safer choice on this pump if you are not confident seating a plunger squarely, because a plunger running even slightly off axis wears its seal on one side and the pump comes back with the same ripple in a few weeks. If you have changed a seal recently and the fault returned, alignment rather than the seal is the thing to look at.

Type
Plunger assembly
Fits
Waters 2695 Alliance
Replaces
WAT270959

Price on request

Enquire

Request a quote
